Product Application
It can be widely used in Paper Carboard Printing,Corrugated Digital Printing.
Main Technical Variables
Inkjet printing function
|
喷墨分辨率 Inkjet resolution |
|
300*600DPI |
600*600DPI |
900*600DPI |
|
理论最大打印速度 Max. Printing speed |
|
100米/分钟 100m/min |
50米/分钟 50m/min |
35米/分钟 35m/min |
|
喷头类型 NozzleType |
|
微压电Epson喷头I3200-A1 Miro electric Espson Inkjet I3200-A1 |
||
|
喷头数量 Nozzle Qty |
|
18/24/30个（标配24个） 18/24/30pcs（Standard 24pcs） |
||
|
喷头介质距离 Inkejet media distance |
|
2MM-4MM |
||
|
最大进纸幅面 Max. Paper feeding Width |
|
1600MM |
||
|
最大打印宽度 Max. Print Wdith |
16喷头：260mm or 520mm 16 Nozzle: 260mm or 520mm |
18喷头：600mm 18 Nozzle: 600mm |
24喷头：800mm 24 Nozzle: 800mm |
30喷头：1000mm 30Nozzle:1000mm |
|
干燥速度 Drying speed |
|
瓦楞纸板即印即干 Corrugated cardboard dry after printing |
||
Main wallboard: The raw material is nodular cast iron, which made by pouring molten iron. More force and wear resistance, high strength, high toughness, stable running and machine life extended by up to 80 %.
Big hub: Integral casting , 5-axis machining, perfectly curved surface, finished in 10 hours continually work, minimize fitting errors.
Former support: The former support is to held the big hub,so it should be strong enough for high speed and long time running.
