Product Parameter
|
Specification |
DPIM-1250-4 |
|
Max resolution分辨率 |
600*600dpi/ 1200*600dpi |
|
Printing Speed印刷速度 |
30m |
|
Material width range材料宽幅范围 |
20mm~330mm |
|
Max feed width进纸最大宽幅 |
1300mm |
|
Printing width印刷最大宽幅 |
1090mm |
|
Material thickness材料厚度 |
0.02~0.5mm |
|
Ink type墨水类型 |
UV Ink |
|
Ink color configuration颜色配置 |
Standard mode is CMYK |
|
Max winding/unwinding最大收放卷直径 |
1250mm |
|
Max unwinding load最大承重 |
2000KG |
|
Material transfer材料传输 |
Servo control for rewinding and unwinding |
|
Relative humidity相对湿度 |
40％ - 60％ (No condensation) |
|
Ambient temperature 环境温度 |
20℃ - 26℃ |
|
Power功率 |
200KW |
|
Power requirements用电要求 |
AC380V/50Hz/320A |
|
Air source气源 |
0.6~0.8Mpa |
|
Weight重量 |
18000KG |
|
Size尺寸 |
10400mm*4500mm*2000mm |
Printing Sample
